Ultrasonic Lace cutting & welding machine
FEATURES
By using ultrasonic wave, it can replace the general sewing machines but without needles & threads.
It can cut and weld simultaneously creating varieties of patterns (by changing the Pattern Rollers) for decorating purpose to beautify your products.
Roller's patterns can also be produced according to your own design.
High tech horn & roller treatment process, holds better lifetime & durability.
APPLICATIONS
Creating decorating patterns over laces, ribbons, fashions, dolls' clothes, bed sheets, table cloths, window shades, rain coats, surgeon's robes, umbrella's edge laces, christmas decorating ornaments etc..
SPECIFICAITONS
Frequency : 20 KHZ
Output power : 1400 W.
Electric source : 220V. 6A 1P
Working width : 1 - 73mm.
Max. speed : 9 Meter/min. ( 18 M/min for model VUS-53 )
Net weight : 140 kg
Dimension : 120 x 55 x 102 cm
